650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders

  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
  • 650 Short Pass Optical Filter Ir Cutoff Filter Customized Camcorders
Place of Origin Beijing, China
Brand Name Kingki
Model Number 650nm cut off filter
Minimum Order Quantity 1piece
Price $40/piece 1-10pieces; $35/piece 11-50pieces; $25/piece >=51pieces
Packaging Details Box, 100mm*80mm*60mm
Delivery Time 7-28 work days
Payment Terms T/T
Supply Ability 1000piece/pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 650 IR-CUT CCD Filter Brand Name Kingki
Place Of Origin Beijing, China Half Wavelength 650 Nm
Work Wavelength 420-620nm Transmittance ≥90%
Cut Off Wavelength 680-1100nm Diameter 10mm Or Custom
Use Camcorders Customized OEM
Highlight

650 Short Pass Optical Filter

,

Short Pass Optical Filter Ir Cutoff

,

Ir Cutoff Filter Customized
You can tick the products you need and communicate with us in the message board.
。 name AOI T wave Tave/% R wave Tavd
e.g. short pass 0° 420-620nm ≥90 680-1100nm ≤1%
。 W0.5 metallic sheath D（mm） purpose quantity 。
e.g. 650 nm no 10 CCD 500 。
Leave a Message
。 name AOI T wave Tave/% R wave Tavd
Product Description

High quality factory customized Camcorders 650 Ir-cut Ccd Filter





Infrared cutoff filter is an optical film with high and low refractive index that is altemately plated on the optical substrate using precision optical coating technology to achieve high permeablity in visible region of 400 to 630 nanometers and near infrared cutoff of 700 to 1100 nanometers. It is mainly used in the digital imaging fields such as camera of mobile phone, built-in camera of computer and car camera. Used to eliminate the effect of infrared light on CCD or CMOS imaging

. name AOI T wave Tave/% R wave Tavd
e.g. short pass 0° 420-620nm ≥90 680-1100nm ≤1%
. W0.5 metallic sheath D(mm) purpose quantity .
e.g. 650 nm no 10 CCD 500 .



YOUR NEEDS

Short Wave Pass Filter
分类 应用 半波长(nm) 透射波长 透射率(%) 截止波长(nm) 透射率(%) 型号
Application Half Wavelength Transmission wavelength Transmitt ance blocking wavelength Transmitt ance Type
Short Wave Pass Filter Industrial camera 650 650 400-620 >50 700-110o ≤1% KK一SP650
ir-cut 650 650 400-630 ≥90% 670-1100 <1% ir-cut650
ir-cut 670 670 400-650 ≥90% 690-1100 <1% ir-cut670
ir-cut 690 690 400-66o ≥90% 710-1100 <1% ir-cut690
ir-cut 710 710 400-670 ≥90% 730-1100 <1% ir-cut710
CDimaging 620 620 400-600 ≥90% 700-1100 <5% KK-BC620
CDimaging 650 650 400-620 ≥90% 700-1100 <5% KK-BG620
Night vision 8o0 800 400-760 ≥90% 830-1100 <1% KK-SP800
infrared reflectance 780 780 400-740 ≥90% 810-1100 ≤1% KK-SP780
Analysis instrument 707 706.5 400-686 ≥90% 726-1100 ≤1% KK-SP706
laser 730 730 400-710 ≥90% 750-1100 ≤1% KK-SP730
laser 750 750 400-730 ≥90% 770-1100 ≤1% KK-SP750
Analysis instrument 767 766.5 400-746 ≥90% 786-1100 ≤1% KK-SP766
Analysis instrument 795 794.7 400-775 ≥90% 815-1100 ≤1% KK-SP795
laser 780 780 400-760 ≥90% 800-1100 ≤1% KK-SP780
laser 830 830 400-810 ≥90% 850-1100 ≤1% KK-SP830
