No Paint High Reflective Film No Bevel Hot Mirror Filter Borofloat Substrate

Model Number Hot mirror
Minimum Order Quantity 5piece
Price $40piece 1-10pieces; $35/piece 11-50pieces; $15/piece >=51pieces; $2/piece>=400pieces
Packaging Details Box, 100mm*80mm*60mm
Delivery Time 7-28 work days
Payment Terms T/T
Supply Ability 1000piece/pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Place Of Origin Beijing, China Brand Name Kingki
Product Name A Hot Mirror Used On Medical Instruments To Prevent Infrared Hot Radial Penetrate Substrate Optical Glass
AOI O Deg Tmin > 70% From 332 - 707nm
Tabs < 5% From 750 - 1200nm Tavg > 85% From 332 - 707 Nm
Application Medical Instrument Diameter 12mm Or Custom
High Light

No Paint High Reflective Film


High Reflective Film No Bevel


Hot Mirror Filter Borofloat

You can tick the products you need and communicate with us in the message board.
AOI Tmin Tabs Tavg Application Specification Quantity
O deg > 70% from 332 - 707nm < 5% from 750 - 1200nm > 85% from 332 - 707 nm Medical instrument Diameter: 12mm Custom
Leave a Message
AOI Tmin Tabs Tavg Application Specification Quantity
Product Description

A hot mirror used on medical instruments to prevent infrared hot radial penetrate


Reflective fims can generally be divided into two major categories, one is a metal reflective fim, and the other is an all-dielectric reflective

film. In addition, there is a metal dielectric reflective film that combines the two. These three high-refiection fims are available.

Generally, metals have a large extinction coefficient. When a light beam is incident on a metal surface by air, the amplitude of light enteringthe metal is rapidly attenuated, so that the light energy entering the metal interior is correspondingly reduced, and the refiected light energyis increased. The larger the extinction coefficient, the faster the attenuation of the light amplitude, and the less the lignt energy entering themetal interior, the higher the reflectivity. People always choose those metals with large optical coefficients and stable optical properties asmetal fim materials. The thin metal material commonly used in the ultraviolet region is aluminum. Aluminum and silver are commonly usedin the visible region, and gold, silver and copper are commonly used in the infrared region. In addition, chromium and platinum are alsocommonly used as fim matenials for special fims. Since materials such as aluminum, silver, and copper are easily oxidized in the air tolower the performance, they must be protected by a dielectric film. Commonly used protective fim materials are silicon oxide, magnesiumfluoride, silicon dioxide, aluminum oxide, and the like.


Hot Mirror Requirement (ENQ.No.OPT-EQ1679)


Substrate material : Borofloat or similar

Diameter : 9.1(+/- 0.2) mm

Thickness : 2.5(+/- 0.2) mm

No paint and no bevel

S&D : 60-40

No Paint High Reflective Film No Bevel Hot Mirror Filter Borofloat Substrate 0


AOI= O deg

Tmin > 70% from 332 - 707nm

Tabs < 5% from 750 - 1200nm

Tavg > 85% from 332 - 707 nm
