Deep Cutoff 530nm Fluorescence Filter Set For Biochemical Analysis

Model Number 530nm Fluorescent Band Pass Filter
Minimum Order Quantity 5piece
Price $70/piece 1-10pieces; $65/piece 11-50pieces; $60/piece >=55pieces
Packaging Details Box, 100mm*80mm*60mm
Delivery Time 7-28 work days
Payment Terms T/T
Supply Ability 1000piece/pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Place Of Origin Beijing, China Brand Name Kingki
Procuct Name 530nm Fluorescent Band Pass Filter Substrate Clear Optical Glass
Center Wavelength 530nm±2nm FWHM 9±1nm
Peak Transmittance T>70% Blocking OD5 @200-1100nm
Size 12*2mm Or Custom Application Biochemical Analysis
Customized OEM
High Light

530nm Fluorescence Filter Set

,

Deep Cutoff Fluorescence Filter Set

,

Biochemical analysis filter

You can tick the products you need and communicate with us in the message board.
Center wavelength FWHM Peak transmittance Cut-off OD Specification Quantity
530nm±2nm 9±1nm T>70% 200-1100nm 5 12*2mm or custom Custom
Leave a Message
Center wavelength FWHM Peak transmittance Cut-off OD Specification Quantity
Product Description

Factory Customized High Performance Deep Cutoff 530nm Fluorescent Bandpass Filter



Fluorescence detection bandpass filter is mainly used for fluorescence microscope and fluorescencequalitative instrument.

Fluorescent filters are widely used in biochemical analysis neighborhoods. Fluorescent filtersgenerally include two types: excitation filter and emission filter.

Excitation filter (Exciting Filter, Exciter Filter, Excitation Filter): in a fluorescence microscope, only afilter that can pass the wavelength of the fluorescence can be passed. There is also the direct use oflaser as a stimulated luminescence.

Emission filters (Emitting Filter, Emission Filter, Barrier Filter, Emitter): select and transmit thefluorescence emitted by the sample, and the other light rays cutoff. The wavelength of the emittinglight is longer than that of the stimulated luminescence. The bandpass filter or the long pass filtercan be selected as the transmitting filter.

Fluorescence detection bandpass filter is mainly used for fluorescence microscope and fluorescencequalitative instrument.

Fluorescent filters are widely used in biochemical analysis neighborhoods. Fluorescent filtersgenerally include two types: excitation filter and emission filter.

Excitation filter (Exciting Filter, Exciter Filter, Excitation Filter): in a fluorescence microscope, only afilter that can pass the wavelength of the fluorescence can be passed. There is also the direct use oflaser as a stimulated luminescence.

Emission filters (Emitting Filter, Emission Filter, Barrier Filter, Emitter): select and transmit thefluorescence emitted by the sample, and the other light rays cutoff. The wavelength of the emittinglight is longer than that of the stimulated luminescence. The bandpass filter or the long pass filtercan be selected as the transmitting filter.



YOUR NEEDS

VIS interference bandpass filters
分类 应用 中心波长(nm) 半宽(nm) 峰值透射率(%) 光学密度OD 型号
Types Application Center Wavelength Band Width Peak Transmittance optical density Type
Element detection
BP filter
SBP365 365 40 50 5 KK-BP365
PBP530 530 8 70 5 KK-BP530
Na BP589.3 589.3 10 70 5 KK-BP589.3
KBP766 766 11 70 5 KK-BP766
Li BP670 670 10 70 5 KK-BP670
fluorescence analysis
BP filter
fluorescence analysis BP470 470 20 70 5 KK-BP470
fluorescence analysis
BP530
520 30 70 5 KK-BP520
Analysis
instrument
BP filter
Analysis instrument BP340 340 10 40 5 KK-BP340
Analysis instrument BP380 380 10 40 5 KK-BP380
Analysis instrument BP405 405 10 40 5 KK-BP405
Analysis instrument BP415 415 10 40 5 KK-BP415
Analysis instrument BP450 450 10 50 5 KK-BP450
Analysis instrument BP455.5 455.5 10 50 5 KK-BP455.5
Analysis instrument BP492 492 10 50 5 KK-BP492
Analysis instrument BP505 505 10 50 5 KK-BP505
Analysis instrument BP508.5 508.5 10 50 5 KK-BP508.5
Analysis instrument BP510 510 10 50 5 KK-BP510
Analysis instrument BP535 535 10 50 5 KK-BP535
Analysis instrument BP540 540 10 50 5 KK-BP540
Analysis instrument BP546 546 10 50 5 KK-BP546
Analysis instrument BP550 550 10 50 5 KK-BP550
Analysis instrument BP570 570 10 50 5 KK-BP570
Analysis instrument BP578 578 10 50 5 KK-BP578
Analysis instrument BP590 590 10 50 5 KK-BP590
Analysis instrument BP600 600 10 50 5 KK-BP600
Analysis instrument BP620 620 10 50 5 KK-BP620
Analysis instrument BP630 630 10 50 5 KK-BP630
Analysis instrument
BP647
647.1 11 50 5 KK-BP647.1
Analysis instrument BP650 650 11 50 5 KK-BP650
Analysis instrument BP670 670 11 50 5 KK-BP670
Analysis instrument BP690 690 11 50 5 KK-BP690
laser BP filter laser BP441.6 441.6 10 50 5 KK-BP441.6
laser BP488 488 5 50 5 KK-BP488-5
laser BP488 488 10 50 5 KK-BP488
laser BP514.5 514.5 5 40 5 KK-BP514.5-5
laser BP514.5 514.5 10 50 5 KK-BP514.5
laser BP532-5 532 5 50 5 KK-BP532-5
laser BP532-10 532 10 50 5 KK-BP532-10
laser BP632.8 632.8 5 40 5 KK-BP632.8-5
laser BP632.8 632.8 11 50 5 KK-BP632.8
laser BP694.3 694.3 5 40 5 KK-BP694.3-5
laser BP694.3 694.3 11 50 5 KK-BP694.3
laser BP706.5 706.5 11 85 5 KK-BP706
laser BP730 730 11 85 5 KK-BP730
laser BP750 750 11 85 5 KK-BP750
laser BP785 785 5 85 5 KK-BP785-5
laser BP785 785 11 85 5 KK-BP785-11
Mercury lamp BP filter Stage lightgreen
BP 525
525 50 85 2 KK-BP525
Mercury lamp BP 546.1 546.1 10 50 5 KK-BP546.1
Mercury lamp BP577 577 10 50 5 KK-BP577
Mercury lamp BP690 690.7 11 50 5 KK-BP690.7
Mercury lamp BP404.7 404.7 10 35 5 KK-BP404.7
Mercury lamp BP435.8 435.8 10 35 5 KK-BP435.8
