Product Details
Place Of Origin Beijing, China Brand Name Kingki
Product Name 3 In 1 ITO Shielding Glass Substrate Clear Optical Glass
Transmittance >93% Resistance Per Square R5-20
Application Communications Advantage Heated Frost-proof
Size 219*165x1.1mm
High Light

3 In 1 ITO Coated Glass Substrate

,

ITO Coated Glass Substrate Heat Resistant

,

ito coated slides Automotive Electronics

You can tick the products you need and communicate with us in the message board.
Product name Brand Name Application Advantage Size Quantity
3 in 1 ITO Shielding Glass Kingki Communications Heated frost-proof 219*165x1.1mm Custom
Leave a Message
Product name Brand Name Application Advantage Size Quantity
Product Description

Electromagnetic Shielding Heat Resistant Frost Proof ITO Transparent Conductive Film 3 in 1 ITO Shielding Glass



The 3 in 1 ITO shielding glass is a transparent conductive film formed by coating a transparent indium tin oxide(ITO) film on the surface of different substrates(glass/PET/PC.) by electron beam evaporation. The resistors achieve EMI electromagnetic interference shielding.

When the electromagnetic wave propagation path encounters the electromagnetic shielding film, it will change the transmission direction of the electromagnetic wave, effectively block the radio wave propagation, block the interference effect of the electromagnetic radiation, ensure the normal operation of the equipment, and avoid the influence of the electromagnetic radiation by the instrument and meter workers. AR glass is anti-reflective glass and AG glass is anti-glare glass.

The 3 in 1 ITO shielding glass is widely used in military, communications,automotive electronics, medical equipment and other industries that require high transparency. Many electronic products, such as equipment windows, computer monitors, and instrumentation displays, often need to prevent the window from being blurred due to the low temperature and the fog. The best way is to use a heated anti- frost ITO transparent conductive film.

The 3 in 1 ITO shielding glass produced by Jinji Aomeng Dream has long been used in the window of communications.

YOUR NEEDS

ITO Transparent conductive film
needs sides R spectral range Rave Tave Tem/℃
e.g.1 A ≤15Ω 420-680nm ≤1% ≥90% ≤100
B 420-680nm ≤0.5% ≥99% ≤100
e.g.2 A ≤12Ω 420-680nm ≤1% ≥90% ≤100
B no coating
e.g.3 A 50±10Ω 420-680nm ≤10% ≥80% ≤300
B BBAR 420-680nm ≤0.5% ≥99% ≤300

needs l*w*h(mm) material using Gluing Electric Num
e.g.1 110x150x1 D263 Monitor NO Y 100
e.g.2 260x150x1 B270 Monitor YES N 300
e.g.3 110x150x1 D263 window NO Y 200

ITO Transparent conductive film
  Description Types
Electromagneticallycompatible low resistance 420-680nm,Rave≤1 %,Tave≥90%, R≤16Ω ITO-1
420-680nm,Tave≥80%, R≤10Ω ITO-2
Thermal defrosting ITO 420-680nm,Tave≥90%, R≤50Ω+10 ITO-3
