Product Details
Product Name 660nm Narrow Bandpass Filter Substrate Optical Glass
Peak Wavelength 660nm FWHM 10nm±2
Peak Transmittance ≥85% Blocking OD4@200-1100nm
Size 12*2mm Or Custom Application Analysis Instrument
High Light

660nm Band Pass Optical Filter

,

Band Pass Optical Filter Narrow

,

narrow band pass filters Analysis Instrument

You can tick the products you need and communicate with us in the message board.
Center wavelength FWHM Tamx Cut-off Application Specification Quantity
660nm 10nm ≥85% 200nm-1100nm Analysis instrument 12*2mm Custom
Leave a Message
Center wavelength FWHM Tamx Cut-off Application Specification Quantity
Product Description

Optical filter 660nm  narrow bandpass filter main use for analysis instrument



660nm narrow bandpass filter is the visiible light filter. Visible light filter widly use of element detection, fluorescence analysis, analysis instrument, laser, mercury lamp.





VIS interference bandpass filters
Types Application Center Wavelength Band Width Peak Transmittance optical density Type
Element detection
BP filter
SBP365 365 40 50 5 KK-BP365
PBP530 530 8 70 5 KK-BP530
Na BP589.3 589.3 10 70 5 KK-BP589.3
KBP766 766 11 70 5 KK-BP766
Li BP670 670 10 70 5 KK-BP670
fluorescence analysis
BP filter
fluorescence analysis BP470 470 20 70 5 KK-BP470
fluorescence analysis
BP530
520 30 70 5 KK-BP520
Analysis
instrument
BP filter
Analysis instrument BP340 340 10 40 5 KK-BP340
Analysis instrument BP380 380 10 40 5 KK-BP380
Analysis instrument BP405 405 10 40 5 KK-BP405
Analysis instrument BP415 415 10 40 5 KK-BP415
Analysis instrument BP450 450 10 50 5 KK-BP450
Analysis instrument BP455.5 455.5 10 50 5 KK-BP455.5
Analysis instrument BP492 492 10 50 5 KK-BP492
Analysis instrument BP505 505 10 50 5 KK-BP505
Analysis instrument BP508.5 508.5 10 50 5 KK-BP508.5
Analysis instrument BP510 510 10 50 5 KK-BP510
Analysis instrument BP535 535 10 50 5 KK-BP535
Analysis instrument BP540 540 10 50 5 KK-BP540
Analysis instrument BP546 546 10 50 5 KK-BP546
Analysis instrument BP550 550 10 50 5 KK-BP550
Analysis instrument BP570 570 10 50 5 KK-BP570
Analysis instrument BP578 578 10 50 5 KK-BP578
Analysis instrument BP590 590 10 50 5 KK-BP590
Analysis instrument BP600 600 10 50 5 KK-BP600
Analysis instrument BP620 620 10 50 5 KK-BP620
Analysis instrument BP630 630 10 50 5 KK-BP630
Analysis instrument
BP647
647.1 11 50 5 KK-BP647.1
Analysis instrument BP650 650 11 50 5 KK-BP650
Analysis instrument BP670 670 11 50 5 KK-BP670
Analysis instrument BP690 690 11 50 5 KK-BP690
laser BP filter laser BP441.6 441.6 10 50 5 KK-BP441.6
laser BP488 488 5 50 5 KK-BP488-5
laser BP488 488 10 50 5 KK-BP488
laser BP514.5 514.5 5 40 5 KK-BP514.5-5
laser BP514.5 514.5 10 50 5 KK-BP514.5
laser BP532-5 532 5 50 5 KK-BP532-5
laser BP532-10 532 10 50 5 KK-BP532-10
laser BP632.8 632.8 5 40 5 KK-BP632.8-5
laser BP632.8 632.8 11 50 5 KK-BP632.8
laser BP694.3 694.3 5 40 5 KK-BP694.3-5
laser BP694.3 694.3 11 50 5 KK-BP694.3
laser BP706.5 706.5 11 85 5 KK-BP706
laser BP730 730 11 85 5 KK-BP730
laser BP750 750 11 85 5 KK-BP750
laser BP785 785 5 85 5 KK-BP785-5
laser BP785 785 11 85 5 KK-BP785-11
Mercury lamp BP filter Stage lightgreen
BP 525
525 50 85 2 KK-BP525
Mercury lamp BP 546.1 546.1 10 50 5 KK-BP546.1
Mercury lamp BP577 577 10 50 5 KK-BP577
Mercury lamp BP690 690.7 11 50 5 KK-BP690.7
Mercury lamp BP404.7 404.7 10 35 5 KK-BP404.7
Mercury lamp BP435.8 435.8 10 35 5 KK-BP435.8
