Professional 340-700nm Optical Band Pass Filter Tunable For Biochemical Light

  • Professional 340-700nm Optical Band Pass Filter Tunable For Biochemical Light
  • Professional 340-700nm Optical Band Pass Filter Tunable For Biochemical Light
  • Professional 340-700nm Optical Band Pass Filter Tunable For Biochemical Light
Model Number BP340-370
Minimum Order Quantity 5piece
Price $10/piece 1-10pieces; $9/piece 11-50pieces; $8/piece >=51pieces
Packaging Details Box, 100mm*80mm*60mm
Delivery Time 7-28 work days
Payment Terms T/T
Supply Ability 10000piece/pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Place Of Origin Beijing, China Brand Name Kingki
Product Name 340-370nm Biochemical Light Filter Substrate Clear Optical Glass
Center Wavelength 340-370nm FWHM 10nm±2nm
Transmittance ≥45% Cut-off Wavelength 200-1100nm
Blocking OD≥5 Size 10*6mm Or Custom
Application Biochemical Analysis Advantage No Drift
Customized OEM
High Light

700nm Optical Band Pass Filter

,

340nm Optical Band Pass Filter

,

tunable band pass filter Biochemical Light
You can tick the products you need and communicate with us in the message board.
Center wavelength FWHM Tamx Cut-off OD Specification Quantity
340-370nm 10nm±2nm ≥45% 200-1100nm 5 10*6mm or custom Custom
Leave a Message
Center wavelength FWHM Tamx Cut-off OD Specification Quantity
Product Description

Professional Good Quality 340-700nm Biochemical light Filter



Biochemical ultraviolet band pass filter, mainly used in UV transmissioninstrument, UV analyzer, portable UV lamp, UV detector, fluorophotometer, liquid chromatographyfixed wavelength UV absorption detector, thin layer chromatography(TLC) observation lamp,UV curing, UV protection, UV analyzer, bioelectrophoresis image analysis system, UV-IR digitalobservation camera system, UV-IR digital observation camera system Nucleic acid proteindetector, ultraviolet visible detector,  UV-B ultraviolet radiation meter, quartz glassUV lamp, liquid chromatograph, ultraviolet observation system, ultraviolet detector, nucleic acidprotein detector, ultraviolet transmission system, ultraviolet photography system, fluorescencespectrophotometer, public security criminal investigation equipment, gel imaging, automaticgel chromatography purification instrument, Gel imaging analysis system, ultraviolet detector,chemiluminescence imaging instrument, etc.

340-370nm biochemical light filter main use in biochemical analysis.



Biochemical bandpass filter
Center wavelength(nm) FWHM(nm) Peak Transmission Average Blocking P/N
340卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-340
405卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-405
450卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-450
492卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-492
505卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-505
545卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-545
600卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-600
620卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-620
670卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-670
700卤2 8~10nm 45%~60% OD5@200-1100nm KK-BF-700
